Ntev:	4m	Daim ntawv thov:	Kev Siv Dej
Xim:	Dawb / ntsuab / txiv kab ntxwv / xiav los yog raws li xav tau	Siab:	PIB 25
Ntim:	Nude Hauv Thawv	Chaw nres nkoj:	NIingbo, Shanghai, Dalian los yog raws li xav tau

Product Description

PN25 SDR6 High Pressure PP-PCT Yeeb Nkab 20 - 160mm Rau Sab Hauv Tsev Dej Kub

PP-RCT yog Polypropylen-random-copolymer nrog hloov kho crystalline qauv thiab nce kub tsis kam

Khoom siv: pp-RCT

Txuj: DIN8077/8078 ISO15874

Khoom yam ntxwv ntawm PP-RCT

Lub cev muaj zog

Lub cev muaj zog		Hom Tus nqi*	Chav tsev	TestMethod
Qhov ntom		905 ua	kg/m3	TS EN ISO 1183
Melt Flow Rate	(230 ℃ / 2.16kg)	0.25	g/10 min	TS EN ISO 1133
Tensile Stress ntawm Yield	(50 hli / min)	25	MPa	ISO 527-2
Tensile Strain ntawm Yield	(50 hli / min)	10	%	ISO 527-2
Modulus ntawm Elasticity nyob rau hauv Tension	(1 hli / min)	900	MPa	ISO 527
Charpy Impact Strength, notched	(+ 23 ℃)	40	kJ/m2	ISO 179/1 eA
Charpy Impact Strength, notched	(0 ℃)	4	kJ/m2	ISO 179/1 eA
Charpy Impact Strength, tsis muaj zog	(-20 ℃)	2	kJ/m2	ISO 179/1 eA
Txhais tau tias Linear Thermal Coefficient ntawm Expansion ntawm 0 ° C txog 70 ℃		1.5	*10-4K-1	TIAB SA 53752
Thermal conductivity		0.24 ib	WK-1m-1	DIN 52612 Ntu 1

Specification

Txoj kab uas hla (mm)	S5 (SDRII, PN12.5)	S4 (SDR9, PN16)	S3.2 (SDRI.L.PN20)	S2.5 (SDRS PH25)
20	2.0	2.3	2.8	3.4
25	2.3	2.8	3.5	4.2
32	2.9	3.6	4.4	5.4
40	3.7	4.5	5.5	6.7
50	4.6	5.6	6.9	8.3
63	5.8	7.1	8.6	10.5
75	6.8	8.4 ib	10.3	12.5 ib
90	8.2	10.1	12.3	15.0 Nws
110	10.0	12.3	15.1	18.3 ib
160	14.6 ib	17.9 ib	21.9 ib	26.6 ib

Qhov zoo

Ntau tshaj 50% Kev Txhim Kho Hauv Lub Sij Hawm Ntev

Tso cai rau cov yeeb nkab nrog cov phab ntsa nyias nyias, qee zaum, cov kab me me tuaj yeem siv tau, uas txo cov khoom siv thiab kev teeb tsa.

Superior Lub Sij Hawm Ntev Durability

Txhim khu kev tiv thaiv rau oxidation thiab kev loj hlob qeeb qeeb ua kom lub neej ua haujlwm ntev.

Txhim kho qhov kub thiab txias

Withstands 1.0 MPa ntawm 90 ℃ rau 50 xyoo-20 ℃ siab dua li cov khoom siv PP-R.

Zoo heev Impact Resistance

Kev sib txuas yooj yim, tib txoj kev raws li tus qauv PP-R.

Tib Txoj Kev Wleding raws li tus qauv PP-R

Xyuas kom yooj yim, txhim khu kev qha installation tsis muaj cov cuab yeej tshwj xeeb.

Smooth & Hygienic Inner Surface

Qhov zoo tshaj plaws rau cov dej haus dej.Smooth thiab huv, yog xaiv zoo rau cov dej haus.

CHUANGRONG yog ib lub tuam txhab sib koom ua lag luam thiab kev lag luam sib koom ua ke, tsim nyob rau xyoo 2005 uas tau tsom mus rau kev tsim khoom ntawmHDPE Pipes, Fittings & Valves, PPR Pipes, Fittings & Valves, PP compression fittings & li qub, thiab muag cov yas yeeb nkab vuam tshuab, yeeb nkab cuab yeej, yeeb nkab kho Clampthiab lwm yam.

CHUANGRONG muaj pab pawg neeg ua haujlwm zoo nrog kev paub nplua nuj. Nws lub hauv paus tseem ceeb yog Kev Ncaj Ncees, Kev Ua Haujlwm thiab Ua Tau Zoo. Nws tau tsim kev lag luam kev sib raug zoo nrog ntau dua 80 lub teb chaws thiab thaj chaw hauv kev lag luam txheeb ze. Xws li Tebchaws Meskas, Chile, Guyana, United Arab Emirates, Saudi Arabia, Indonesia, Malaysia, Bangladesh, Mongolia, Russia, Africa thiab lwm yam.

Txais tos tiv tauj peb kom paub meej cov khoom thiab kev pabcuam tshaj lij.

Thov xa email rau:chuangrong@cdchuangrong.comlos yog Tel:+86-28-84319855
